KRUZR 10
LOUNGER
Relax. Explore.
The Lounger is the bookend to a perfect day. It’s a great place to start with a hot cup in the morning and cozy place to kick back in the evening. It’s up to you two to decide how much space is in between.
The KRUZR 10 is the perfect fit for 1 ton dually and flat bed trucks. Note: All vehicles differ in GVWR and all campers vary in weight due to options and accessories. Please verify your vehicle GVWR capacity.
Check out the full line-up of color options for the campers.
Engineered
for Luxury
Standard Specifications
- Approximate 10'6" Clearance on Stock Suspension 1 Ton Truck
- 7'7" Wide Exterior
- 9'2" Floor Exterior
- 4 season R-13 Closed Cell Spray Foam Insulation
- 2"x2" and 2"x4" and 2"x6" LVL Wood Frame Construction
- Approximate 3670 lbs Dry weight, includes 460 Ah Epoch Lithium Battery and 3k Watt Victron Inverter
- 6’5” to 6'7" Head Clearance Inside
- 34-36" center of gravity depending on how camper is equipped
- 75 Gal Freshwater
- 20 Gallon (30 Gallon for CA Flat Bed Builds), 3.5 Season Gray Tank with Trap (Note: Quick water divert to ground for below freezing use)
The Space
you need
Standard Equipment:
- North/South Layout
- Lounger chairs
- Overcab 6” Green Tea Memory Foam Residential Queen Mattress
- 20/22 Gauge Stainless Steel / .040 Aluminum Roof System
- 10k BTU Wall Mount Air Conditioner
- Conture Convection/Air Fryer/Microwave
- Single Burner True Induction Cooktop
- Pull-out Trash Cans
- 2 - 20 lb. LP Tank Capacity
- Truma-Combi Eco Plus Upgrade (Includes 5.3 cu ft Vitrifrigo DC Refrigerator)
- 3K Watt Victron Inverter. Includes Epoch 12V 460Ah Heated & Bluetooth & Victron Comms LiFePO4 Battery
- 660 Watt Zamp Solar Kit w/Victron SmartSolar MPPT 100/50 Charge Controller w/Bluetooth
- Cerbo GX / GX Touch 50 Screen
- SmartShunt 500A/50mV
- Orion XS 12/12-50A DC-DC Orion XS - Victron Energy
- 24 Gauge Stainless Steel Shower, Fully Enclosed Wet Bath or Sliding Toilet Dry Bath with Molded Sink, Stainless Steel Vanity Mirror/Shampoo Holder. Includes Thetford Cassette Toilet C224-CW Model
- Vented Thermal Pane Windows
- 1.25” Walnut Butcher Block Counters & Tables w/ Undermount Stainless Sink
- MAXXFAN Deluxe Model 7500k Fan
- Soft Touch Ceiling with Accent Strips
- Maximum Drawer & Cabinet Storage
- CNC 13 Ply Walnut Veneer Cabinet Door & Drawer Faces w/ Soft Close & Locking Hardware
- Outside Aux Shower
- Pull-out Tables
- Roller Shades & Valances
- Skylight w/ Blackout Shade & Screen
- 12 Volt Electric Rieco-Titan Jack
- Jack Brackets
- Rack Rails
- LVF (Luxury Vinyl Flooring) thru out Camper
- Halo Rearview Camera
- Exterior Porch Light - Amber & White w/White LED Side Lighting
- Awning, Rear Roof Mount
- Interior LED Lighting
- Multiple USB & 120V Outlets
- Screen Door w/Window
Note: Some items pictured, may have changed due to technology advancements or supplier issues.
Endless
options
All the configuration you need
- Diesel Truma Combi D Upgrade - $4,390
- Entertainment Package (27" Sylvox 12 Volt HD LED TV w/ Bluetooth / King OmniPro HD TV Antenna) - $1,790
- Communications Package (Peplink 5G Mobile Internet Bundle) - $2,890
- Starlink Mini - $1,190
- One additional 460 Ah Epoch Lithium Battery (920 Total Ah) 12V 460Ah LiFePO4 Battery, Group 8D Size, IP67, Heated, Bluetooth & Victron Comms - $2,490
- Two additional 460 Ah Epoch Lithium Batteries (1380 Total Ah) 12V 460Ah LiFePO4 Battery, Group 8D Size, IP67, Heated, Bluetooth & Victron Comms - $4,990 NOTE: Only available with CA Option
- Laveo Dry Toilet Upgrade - $990
- Additional 440 Watts of Zamp Solar - $1,990
- Additional 660 Watts of Zamp Solar - $2,990
- Awning, Driver & Passenger Side - $4,490
- Standard Width Fast Back - $0
- Standard Width Flat Back - $1,990
- CA/Flatbed Wide Body Fast Back - $1,990
- CA/Flatbed Wide Body Flat Back - $2,990
- Tern Overland Door Upgrade - $1,690
Note: Some items pictured, may have changed due to technology advancements or supplier issues.
Accessories
Galore
Reimagining Accessories
- Rack Rails - Standard Equipment
- 18" thru 36" Flat Bed Garage - Size to be determined upon Coach Series and length of bed - $6,990 Installed
- Hanger Brackets for Garage Installed to Camper - $690
- Flat Bed Boxes (Set of 2) - $4,990 Installed
- Fish & Ski Locker - $2,490 Installed
- Finder/Keeper Bracket - $290 Installed
- Overland Pack with Fold & Go Stairs - $3,990 Installed
- Overland Pack Tower - $2,990 Installed
- Max Pack with Fold & Go Stairs - $4,990 Installed
- Max Pack Tower - $2,990 Installed
- Side Entry/Pack Away Porch - $990 Installed
Note: Some items pictured, may have changed due to technology advancements or supplier issues.
Interior
Shown in Cascade Decor.
Exterior
Shown in Brushed Aluminum, Polar White, and Clovermist.
